Condition: Used

In excellent working condition, tested and within specification.

Highlights

• Extended calibration wavelengths for very high performance: 600 adjustable wavelengths for the OLA-54 and 400 adjustable wavelengths for the OLA-55.
• An extremely long battery operation time of >1000 h.
• Absolute and relative attenuation setting
• Low minimum insertion loss due to new optical design.

Applications

• Emulate fiber loss for testing system dynamics.
• OLA-55 for testing up to 40 Gbps systems together with bit error rate testing (BERT).
• For system installation and maintenance of multimode fiber (OLA-54) and singlemode fiber (OLA-55).

Key Features

• The SMARTWheel for precise and fast manual setting
• The SMARTStar graphical user interface for fast, easy, and straightforward operation.
• The SMARTEnergy power supply management system.
• A USB port for remote operation.
• Traceable measurements to NIST/PTB standards for confidence in accuracy.
• A robust, shock-proof, and splash-proof design for field operation.
• One-handed operation in the field.
• Quick start operation, requiring no warm-up time and reducing testing time.

Specifications

Adjustable Wavelength Range: 1260 to 1650 nm in 1 nm increments

Fiber Type: 9/125 µm

Calibrated Wavelengths: 1300 nm, 1310 nm, 1550 nm, 1625 nm

Display Range: 2.0 to 60 dB

Minimum Insertion Loss: < 2.0 dB

Linearity: ± 0.2

Repeatability of Attenuation Setting: ± 0.1 dB

Total Attenuation Accuracy: ± 0.8 dB

Setting Type: Continuous over the entire range

Function: Bi-directional

Displayed Value: Absolute or relative attenuation value

Max. Permitted Level: +23 dBm
