Condition: Used

The VIAVI E980TUXOSX is the long-format interconnect cable kit used to connect the OSX8000 external optical switch to the OTU-8000 Optical Test Unit mainframe. The cable features an 8-pin mini-DIN connector on one end and a 3-pin circular connector with a knurled locking collar (blue marker band) on the other.

Included in this sale:
• 1x VIAVI E980TUXOSX long interconnect cable (8-pin to 3-pin with locking collar)

The images provided are of the actual item you will receive. Please review them carefully for the cosmetic condition and what is included in the sale.

The VIAVI E980TUXOSX (also referenced as E98OTUXOSX) is a purpose-built interconnect cable kit designed to connect the OSX8000 external optical switch to the OTU-8000 Optical Test Unit mainframe. It is a required accessory when expanding the OTU-8000's optical port capacity using one or more OSX8000 external switches.

The OSX8000 is a 1x36 port external optical switch that supplements the internal switching capability of the OTU-8000 platform. When the OSX8000 is used, it replaces the internal OTAU plug-in module, and this cable provides the physical control and communication link between the two units.

The OTU-8000 Optical Test Unit is a rack-mounted, automated fibre test platform that combines OTDR and optical-switch technology to provide continuous OTDR monitoring of multiple fibres across the network. The platform is fully modular and supports a wide range of OTDR modules, wavelengths, and dynamic ranges.

Compatible System — OTU-8000 Base Unit Specifications:
Form Factor: Rack-mounted, 2RU
Width: 19", 21" (ETSI), or 23"
Depth: 260 mm (ETSI) / 280 mm (19" or 23")
Operating Temperature: -20 to 50°C
Power Supply: -48 V DC or AC (with optional converter)
OSX8000 Optical Ports: 1x36 per external switch unit
Maximum Optical Switch Ports (system): Up to 1080 ports
Network Management: Compatible with VIAVI ONMSi and SmartOTU
Country of Origin: France

Key Use Cases:
- Automated continuous OTDR monitoring of multiple fibres
- Expansion of optical test port capacity in central office or remote deployments
- Long-haul and FTTx network monitoring
- Fault detection, fibre degradation monitoring, and intrusion detection
- Integration with ONMSi network management software

VIAVI OTU-8000 Optical Test Unit — official user manual including OSX8000 connection and installation instructions: Download PDF

VIAVI OTU-8000E V2 user manual — covers OSX8000 integration and E98OTUXOSX cable usage: Download PDF

VIAVI OTU-8000 Optical Test Unit — product datasheet with specifications and ordering information: Download PDF
