Ocean Optics ISP-80-8-I top view showing 8mm PTFE-lined sample port opening with white diffusing interior coating visible

Ocean Optics ISP-80-8-I bottom view showing machined aluminium base plate with four mounting holes and central hex socket

Tested

14 Day Money Back Guarantee

Great Value

Global Shipping

Ocean Optics ISP-80-8-I Integrating Sphere 80mm Irradiance

Name: Ocean Optics ISP-80-8-I Integrating Sphere 80mm Irradiance
Brand: Ocean Optics
SKU: 7751 7E04 EB02
Price: 675.75 GBP
Availability: InStock

The Ocean Optics ISP-80-8-I is an 80mm integrating sphere designed for irradiance measurement of LEDs, lasers, and other light sources via SMA 905 fibre optic connection to a spectrometer.
• Broad 200–2500 nm spectral range with PTFE sphere coating delivering >98% reflectivity (400–1500 nm)
• Large 80mm sphere diameter for superior light collection and measurement uniformity
• Compact yet substantial build at 107mm diameter × 117mm height — ready for lab and R&D use

Manufacturer

Ocean Optics

Model

ISP-80-8-I

Condition

Used

In stock

SKU

7751 7E04

£675.75

Accessories / Misc
Electronic T&M

Make an Offer

Ocean Optics ISP-80-8-I Integrating Sphere 80mm Irradiance

£675.75

Condition: Used

The Ocean Optics ISP-80-8-I is an 80mm irradiance integrating sphere (Serial No. 050090050) with an 8mm sample port and ISP-PORT-2 Ø30mm port configuration. The PTFE-lined interior provides a highly Lambertian diffusing surface across the full 200–2500nm spectral range.

Included in the sale:
• 1x Ocean Optics ISP-80-8-I 80mm Integrating Sphere (Serial No. 050090050)

The images provided are of the actual item you will receive. Please review them carefully for the cosmetic condition and what is included in the sale.

Product Overview

Condition: Used

Included in the sale:
• 1x Ocean Optics ISP-80-8-I 80mm Integrating Sphere (Serial No. 050090050)

The images provided are of the actual item you will receive. Please review them carefully for the cosmetic condition and what is included in the sale.

Manufacturer's Description

The Ocean Optics ISP-80-8-I is an irradiance integrating sphere designed to couple to Ocean Optics spectrometers and optical fibres for measuring the spectral output of LEDs, lasers, and other light sources. The sphere interior is constructed from a proprietary PTFE-based sintered diffusing material that provides a Lambertian surface with exceptionally high and uniform reflectivity across the UV-VIS-NIR spectrum. The large 80mm sphere diameter makes it particularly well suited to applications requiring high collection efficiency. Connection to a spectrometer is made via SMA 905 fibre optic connector. The ISP-80-8-I does not include an LED adapter but accepts a wide range of external light sources through its 8mm sample port.

Model: ISP-80-8-I
Sphere Diameter: 80 mm
Sample Port Diameter: 8 mm
Spectral Range: 200–2500 nm
Sphere Coating: PTFE-based sintered diffusing material
PTFE Reflectivity: >98% (400–1500 nm); >95% (250–2500 nm)
Connector: SMA 905
Dimensions: 107 mm diameter × 117 mm height
Weight: 1650 g
Maximum Fibre Core Diameter: 400 μm
LED Adapter: No
Gloss Trap: No
