Condition: Used

A used Keysight E5381B Differential Flying Lead Probe Set in good working condition. The E5381B is compatible with any Keysight logic analyzer with a 90-pin cable connector and includes a variety of high-performance accessories for connecting to IC pins, traces, pads, vias, and surface mount components — ideal for situations where probing points are dispersed or were not designed in.

Typically included with this probe set:
• Differential flying lead probe assembly with 90-pin connector
• Coaxial tip resistors (82 Ω)
• Damped wire accessories
• 3-pin header adapters
• Socket adapters
• 82 Ω resistor trimming template

The Keysight E5381B is a 17-channel differential flying lead probe set for use with Keysight logic analyzers equipped with a 90-pin cable connector. It is the direct replacement for the E5381A and shares the same fundamental functionality and core specifications. The probe is optimised for general-purpose probing scenarios where target signals are physically dispersed or where a designed-in connector is not available. A variety of supplied accessories allow connection to IC pins, solder-attached surface mount components, vias, pads, traces, and other PCB features.

Key Features:
- 17-channel probe with differential or single-ended signal acquisition
- Suited for acquiring signals from randomly located points on a target board
- Compatible with any Keysight logic analyzer with a 90-pin cable connector
- Supplied accessories support multiple probing configurations optimised for signal fidelity
- Unused clock inputs can be used as additional data inputs
- Direct replacement for the E5381A differential flying lead probe

Technical Specifications:
Number of Channels: 17 (16 data + 1 clock)
Data Channel Type: Single-ended or differential
Clock Channel Type: Single-ended or differential
Maximum Data Rate: 1.5 Gb/s
Equivalent Load Capacitance (coaxial tip config): 0.9 pF
Equivalent Load Capacitance (3-pin header config): 1.0 pF
Equivalent Load Capacitance (socket adapter config): 1.1 pF
Equivalent Load Capacitance (damped wire config): 1.3 pF
Minimum Signal Amplitude: 200 mV Vmax–Vmin
Connector Interface: 90-pin cable connector
Compatible Instruments: Keysight logic analyzers with 90-pin pod connections (e.g. 16860A series, 16700 series, and others)
Connection Methods: Coaxial tip with 82 Ω resistor, 3-pin header, socket adapter, damped wire solder attachment
Predecessor Model: E5381A (obsolete)

Keysight E5381B Differential Flying Leads Probe Set User Guide (official Keysight PDF): Download PDF

Keysight Probing Solutions for Logic Analyzers Data Sheet (pub. 5968-4632E) — covers E5381B specifications and configurations: Download PDF

Keysight Probing Solutions for Logic Analyzers Data Sheet — mirror copy including E5381B probe configurations table: Download PDF
