Condition: Used

This is a used Keysight / Agilent E4401-60364 (assembly part number E4401-20364, REV 002) RS-232 and parallel port upgrade board for the Agilent ESA series spectrum analysers. The board is supplied as shown, with no additional accessories included.

What is typically included:
• E4401-20364 REV 002 interface PCB assembly (Option 1AX upgrade board)

The Agilent / Keysight E4401-60364 is the hardware upgrade kit that installs Option 1AX — the RS-232 and Parallel Interface option — into the Agilent ESA-E and ESA-L series spectrum and EMC analysers. It is a field-installable, post-sale retrofit option compatible with all ESA series models.

Option 1AX replaces the need for a GPIB connection (Option A4H) and occupies one of the instrument's internal expansion slots. Only one remote interface option (Option A4H or Option 1AX) can be installed at a time. The RS-232 interface supports full remote analyser operation and programming via SCPI commands, while the parallel port supports printer output only.

Compatible Instruments:
ESA-E Series: E4401B, E4402B, E4404B, E4405B, E4407B, E4408B
ESA-L Series: E4403B, E4408B, E4411B

RS-232 Serial Interface:
Connector: 9-pin D-SUB male
Function: Remote analyser operation (SCPI)

Parallel Interface:
Connector: 25-pin D-SUB female
Function: Printer port only

Option Compatibility: Not compatible with Option A4H (GPIB); occupies one expansion slot
Installation Type: Post-sale field retrofit
Performance Verification Required: Displayed Average Noise Level; Residual Responses (no hardware adjustments required post-installation)
BenchLink Spectrum Analyser software (B70/E4444A) also requires Option A4H or Option 1AX for PC connectivity.

Agilent ESA Series Spectrum Analyzers Getting Started Guide (covers Option 1AX installation context): Download PDF

Agilent ESA-E Series Spectrum Analyzers Data Sheet (includes Option 1AX specifications): Download PDF

Agilent ESA-E Series Spectrum Analyzers Specifications Guide E4401-90490: Download PDF

Keysight ESA-E Series Spectrum Analyzer Data Sheet (5989-9815): Download PDF

Agilent ESA / EMC Option Upgrades — Option 1AX Test Recommendations: Download PDF

Agilent ESA-L Series Spectrum Analyzers Specifications Guide (includes Option 1AX specs): Download PDF

Agilent ESA-E Series Spectrum Analyzers Configuration Guide (upgrade ordering reference): Download PDF
