Condition: Used

The Keysight U2653A is a 64-channel isolated digital output USB module from the U2600A series. It features high-speed USB 2.0 connectivity, standalone and modular operation, interrupt function, and Virtual Port grouping, making it well suited to industrial control and automated test applications. A BenchVue software licence (BV0025B) is included.

Typically includes:
• BenchVue software licence (BV0025B)

The Keysight (formerly Agilent) U2653A is part of the U2600A Series USB Modular Isolated Digital I/O devices. It provides 64-bit isolated digital output in a compact, paperback-sized USB module that can operate as a standalone instrument or slot into a U2781A USB modular instrument chassis.

The U2600A Series uses opto-isolation to separate electrical connections between circuits, protecting the host PC system from transient voltage spikes on industrial signal lines. The robust 1250 Vpeak transient isolation protection makes it safe for direct connection to a wide range of industrial sensors and actuators.

Key Features:
• 64 opto-isolated digital output lines
• High-speed USB 2.0, USBTMC-USB488 standard interface
• Plug-and-play installation — no PC card slot required
• Standalone or modular (chassis-based) operation
• Interrupt function for automatic change-of-state detection
• Virtual Port grouping: group any 8 output bits into a single virtual DIO port
• Compatible with Keysight VEE, NI LabVIEW, MATLAB R2007a, Microsoft Visual Studio (VB, C++, C#)
• SCPI command set supported
• Keysight Measurement Manager (AMM) software included for quick setup and data logging
• BenchVue software licence (BV0025B) included

Specifications:
Digital Output Lines: 64 opto-isolated
Output Voltage Range: 5 V to 35 V (external supply)
Isolation Protection: 1250 Vrms (transient 1250 Vpeak)
USB Interface: High-speed USB 2.0, USBTMC-USB488
Connector Type: 100-pin SCSI-II
Standalone / Modular: Both supported
Chassis Compatibility: U2781A USB Modular Instrument Chassis
Terminal Block Options: U2903A or U2904A (optional)
Operating Temperature: -20 °C to 70 °C
Altitude: Up to 2,000 m
Safety Compliance: IEC 61010-1:2001 / EN 61010-1:2001
Country of Origin: USA

Typical Applications:
• Industrial automation and control
• Relay, actuator and valve driving
• Isolated data communication
• Logic level interfacing
• Laboratory automation
• Design validation and functional test systems
