EXFO Fiber Optic OTDR E-2000 Adapter Connector
Model: E-2000
Condition: Used
In stock: 0
SKU: 5694 6C02
- Fiber Optics
- Passive Components
Choose options
Condition: Used
This is a used EXFO E-2000 fibre optic adapter connector for EXFO OTDRs and compatible EXFO test instruments. Part of the EXFO EUI (EXFO Universal Interface) system, it allows the instrument port to accept E-2000 terminated fibre patchcords with a simple push-and-twist action.
Typically includes:
• E-2000 EUI adapter connector
The EXFO E-2000 Adapter Connector is part of EXFO's Universal Interface (EUI) system — the industry's first built-in interchangeable connector interface for fibre optic test instruments. The EUI system is designed to allow technicians to quickly and easily change the connector type on compatible EXFO OTDRs, standalone optical power meters, and light sources without tools or complex procedures.
The E-2000 variant (designated EUI-95 in APC/EA configuration and EI-EUI-95 in UPC/EI configuration) provides a precise, reliable interface for instruments that need to connect to E-2000 terminated fibre cables — commonly used in high-density and telecommunications-grade singlemode fibre networks.
Key Features:
Connector Type: E-2000 (LSH)
Interface System: EXFO Universal Interface (EUI)
Polishing Options: APC (angled) or UPC (non-angled)
Installation: Tool-free push-and-twist mechanism onto EUI fixed baseplate
Fibre Type: Singlemode (9/125 µm)
Low insertion loss
Low backreflection
Excellent repeatability
Precise machining ensures ferrule concentricity
Direct access to plug surface for convenient cleaning
Compatibility: All EXFO OTDR models featuring EUI baseplate, EXFO FiberBasix 100 and 500 Series light sources, EXFO standalone power meters with built-in EUI port
Available connector types in EUI series: FC, SC, ST, DIN 47256, HMS-10/AG, E-2000
Compliant with EXFO ISO 9001 certified manufacturing standards
Typical Use Cases:
Field fibre optic network testing and certification
Telecommunications infrastructure installation and maintenance
Singlemode fibre characterisation using OTDR trace analysis
Connector type conversion for multivendor fibre environments
Product Overview
Condition: Used
This is a used EXFO E-2000 fibre optic adapter connector for EXFO OTDRs and compatible EXFO test instruments. Part of the EXFO EUI (EXFO Universal Interface) system, it allows the instrument port to accept E-2000 terminated fibre patchcords with a simple push-and-twist action.
Typically includes:
• E-2000 EUI adapter connector
Manufacturer's Description
The EXFO E-2000 Adapter Connector is part of EXFO's Universal Interface (EUI) system — the industry's first built-in interchangeable connector interface for fibre optic test instruments. The EUI system is designed to allow technicians to quickly and easily change the connector type on compatible EXFO OTDRs, standalone optical power meters, and light sources without tools or complex procedures.
The E-2000 variant (designated EUI-95 in APC/EA configuration and EI-EUI-95 in UPC/EI configuration) provides a precise, reliable interface for instruments that need to connect to E-2000 terminated fibre cables — commonly used in high-density and telecommunications-grade singlemode fibre networks.
Key Features:
Connector Type: E-2000 (LSH)
Interface System: EXFO Universal Interface (EUI)
Polishing Options: APC (angled) or UPC (non-angled)
Installation: Tool-free push-and-twist mechanism onto EUI fixed baseplate
Fibre Type: Singlemode (9/125 µm)
Low insertion loss
Low backreflection
Excellent repeatability
Precise machining ensures ferrule concentricity
Direct access to plug surface for convenient cleaning
Compatibility: All EXFO OTDR models featuring EUI baseplate, EXFO FiberBasix 100 and 500 Series light sources, EXFO standalone power meters with built-in EUI port
Available connector types in EUI series: FC, SC, ST, DIN 47256, HMS-10/AG, E-2000
Compliant with EXFO ISO 9001 certified manufacturing standards
Typical Use Cases:
Field fibre optic network testing and certification
Telecommunications infrastructure installation and maintenance
Singlemode fibre characterisation using OTDR trace analysis
Connector type conversion for multivendor fibre environments
