Condition: New other (see details)

The Mini-Circuits CBL-1M-SMNM+ is a TEST FLEX precision coaxial test cable in new condition. It offers a 1-metre length with an SMA-Male connector on one end and an N-Male connector on the other, operating from DC to 18 GHz at 50Ω impedance.

Typically includes:
• CBL-1M-SMNM+ precision test cable (1 metre, SMA-Male to N-Male)

The Mini-Circuits CBL-1M-SMNM+ is part of the TEST FLEX series of precision RF test cables designed for high-performance measurement and production test applications. It is a 50Ω coaxial cable assembly with SMA-Male and N-Male connectors, covering a frequency range from DC to 18 GHz. The cable features extra-rugged construction with strain relief, triple shielding for excellent shielding effectiveness, and stainless steel connectors rated for long mating-cycle life. It delivers superior stability of insertion loss, VSWR, and phase versus flexing, making it well-suited for repeated connection and disconnection in demanding test environments. The cable is RoHS compliant and backed by Mini-Circuits' 6-month product guarantee covering connector attachment.

Model: CBL-1M-SMNM+
Series: TEST FLEX
Frequency Range: DC to 18 GHz
Impedance: 50Ω
Cable Length: 1.0 M (3.28 ft)
Connector 1: SMA-Male, Straight
Connector 2: N-Male, Straight
Max Insertion Loss (at 18 GHz): approx. 2.2 dB
Operating Temperature: -55°C to +105°C
Shielding: Triple shield
Connector Material: Stainless steel
Compliance: RoHS
Guarantee: 6 months (connector attachment)

Applications:
• High-volume production test stations
• Research and development laboratories
• Environmental and temperature test chambers
• Replacement for OEM test port cables
• Field RF testing
• Cellular infrastructure site testing

Mini-Circuits CBL-1M-SMNM+ Official Datasheet (PDF): Download PDF
