Condition: Used

The PCTEL OP451 is a 450 MHz – 6 GHz multi-band magnetic mount antenna with GPS, tested and confirmed working. The magnetic mount design allows quick installation on any ferrous metal surface, making it well suited for drive test and wireless network measurement applications.

Included with this product:
• PCTEL OP451 Multi-Band Magnetic Mount Antenna (450 MHz – 6 GHz)
• GPS antenna

The PCTEL OP451 is a high-performance multi-band magnetic mount outdoor antenna designed for use with PCTEL scanning receivers in mobile wireless network drive testing and GNSS applications. It delivers wide band coverage across 450 MHz to 6 GHz frequencies with excellent VSWR performance and requires no tuning across its operating range. The omni-directional antenna is vertically polarised and engineered to support testing across full-spectrum UHF, TETRA, and sub-6 GHz cellular frequencies including LTE, WCDMA, GSM, and 5G NR sub-6 GHz bands. Its robust, impact-resistant housing is suited to outdoor mobile deployments. The magnetic mount base enables fast, tool-free installation on any ferrous metal vehicle surface or grounding plate.

Frequency Range: 450 MHz – 6 GHz
VSWR: < 2.0:1
Nominal Impedance: 50 Ω
Polarisation: Vertical
Mount Type: Magnetic mount
Antenna Dimensions: 4.2" H x 5.1" OD (107 mm H x 130 mm OD)
Cable Length: 12 feet (3.7 m)
Application: Mobile outdoor drive test, GNSS/GPS, wireless network measurement
Compatible Equipment: PCTEL SeeGull IBflex, HBflex, and compatible scanning receivers

PCTEL OP451, OP697, OP278H & OP286H Outdoor Mobile Antennas Data Sheet (PDF): Download PDF

PCTEL Antennas for Scanning Receivers Brochure 2023 — includes OP451 specifications (PDF): Download PDF

PCTEL Antennas for Scanning Receivers Brochure Rev C June 2021 — includes OP451 specifications (PDF): Download PDF
